The RIDGID® Model HC-300 Hole Cutting Tool is designed to cut holes up to 3″ (76 mm) diameter into steel pipe. The multiple hole size allows the use of fittings such as Mechanical T®, Vic-O-Let™, Weld-O-Let™ and others for branching unpressurized pipelines. An integral motor and gear reduction optimizes the performance and saw life. A single-feed handle and ON/OFF switch allows for easy operation. The Model HC-300 offers great features that translate into unparalleled field and shop performance.
Features
- Quick Connecting Two-piece Design – This unique design allows for easy mounting, transport and set up. This is particularly useful when working off a ladder or overhead.
- Single-Hand Chain Latching – The Model HC-300 features a patented spring-loaded chain that saves time and significantly aids set up and operation.
- Ergonomic Design – With all controls at the operator’s fingertips, the tool has been designed for maximum productivity.
- High Speed – With a powerful 1.2 HP, 11 Amp motor, the Model HC-300 delivers 360 RPM to quickly bore holes while optimizing hole saw life.
- Horizontal and Vertical Flats – Ensures perpendicular cutting.
Specifications
| Hole Cutting Capacity |
Up to 3″ (76 mm). |
| Pipe Diameter Mounting Range |
1-1/2″ (38 mm) to 8″ (200 mm). |
| Chuck Size |
1/16″(1.6 mm) to 1/2″ (13 mm). |
| Motor |
Universal, 115V/230V, 60Hz. Approved by CSA to CSA and UL standards. |
| Output Speed |
360 RPM (no load). |
| Arbor Capacity |
Up to 7/16″. |
| Weight |
31 lb. |
| Height |
12.8″. |
| Length |
11.9″. |
| Width |
13.2″. |
|
Approved by CSA to CSA and UL standards, 115V/230V |
